High voltage oil type electric power transformer 200kva 500kva 630kva 800kva 1000kva
High voltage oil type electric power transformer 200kva 500kva 630kva 800kva 1000kva is different from the general oil immersed transformer. It cancels the oil storage tank and uses the corrugated plate heat sink of the oil storage tank to radiating & cooling, which to compensate the increase or decrease of oil volume by its elastic expansion and contraction.
The application of High voltage oil type electric power transformer 200kva
All series of transformer are suitable for 10kV, 20kV and 35kV power transmission and distribution systems, and can be used for power and lighting in residential areas, commercial streets, industrial and mining enterprises and rural areas.
·Order instructions:
1. The customer needs provide main parameters of the transformer (input and output voltage, capacity, loss, etc.)
2. Other customer requirements
Note: Due to continuous product improvement, the dimensions provided in this sample are for reference only. If necessary, our company can design and produce according to user requirements. Please contact the company in time.
| Main technical parameters |
| Main circuit rated voltage(V) | .......................... | Ac 400 (600) |
| Rated voltage of auxiliary circuit (V) | .......................... | Ac 220/380 (400) dc 110/220 |
| Rated frequency (Hz) | .......................... | 50(60) |
| Rated insulation voltage(V) | .......................... | 690(1000) |
| Rated current(A) | The level of bus | ≤6000 |
| Rated short-time bus withstand current (kA/1s) | .......................... | 50,80 |
| Rated peak withstand current of bus (kA/0.1s) | .......................... | 105,176 |
| Power frequency test voltage (V/1min) | main circuit | 2500 |
| Auxiliary circuit | 1760 |
| bus | Three-phase four-wire system | A,B,C,PEN |
| Three-phase five-wire system | A,B,C,PE,N |
| Protection grade | .......................... | IP30
|
Company introduction
Qingdao Hengfengyou group specializes in the development research, manufacturing and service of power transformers for 30 years. At present, the company has 10 senior engineers, 30 senior technicians, more than 200 employees, with an annual output value of 50 million US dollars and an annual production capacity of more than 10 million kVA. Hengfengyou is a large-scale enterprise in the field of power transmission and distribution equipment manufacturing. With high-quality products and perfect service system, It now provides reliable power transformer products and services for more than 50 countries and regions around the world. It has established a good reputation and image of "HFY" brand in the global market, and won extensive trust and praise from customers.
